IoT-Based Multiple Battery Charging System Using a Single Charger

The IoT-Based Multiple Battery Charging System Using a Single Charger is designed to charge multiple batteries using one common charger. The ESP32 monitors the voltage, charging current, temperature, and charging status of each battery and automatically selects the appropriate battery for charging.

When one battery reaches the required charging level, the system automatically disconnects it and switches the charger to the next battery. All battery parameters and charging status can be monitored remotely through an IoT web dashboard.

Objectives

✅ Multiple Battery Charging Using One Charger
✅ Automatic Battery Selection
✅ Sequential/Smart Charging
✅ Individual Battery Voltage Monitoring
✅ Charging Current Monitoring
✅ Battery Temperature Monitoring
✅ Automatic Full-Charge Cut-Off
✅ Overcharge Protection
✅ Fault & Abnormal Battery Detection
✅ IoT-Based Remote Monitoring
✅ Charging History & Data Logging

Web Dashboard Features
🔋 Battery 1–N Status
⚡ Battery Voltage
🔌 Charging Current
🌡️ Battery Temperature
🔄 Currently Charging Battery
📊 Charging Progress
✅ Full-Charge Status
⚠️ Fault/Overheat Alert
📅 Charging History
🌐 Remote Monitoring
📈 Battery Performance Graphs
Applications

🔋 EV Battery Packs
🛵 Electric Vehicles
🚗 Automotive Batteries
☀️ Solar Energy Systems
🔋 UPS & Backup Systems
🏭 Industrial Battery Banks
🚜 Agricultural Equipment
🎓 Battery Management Research

📦 Includes:
✅ Complete Source Code • IoT Web Dashboard • Circuit Diagram • PCB Design • Documentation • Project Report • Installation Guide • User Manual • Technical Support
